Introducing the Corvil 10000
High performance 100Gbps capture and analytics appliance.
100Gbps
Sustained capture to disk
2X
Smaller Appliance 2U Form Factor
100M
Packets Per Second1
360TB
Effective data storage with compression
Corvil bare-metal appliances, supplied at cost, perform analytics, packet capture and export even through sudden large and extended traffic bursts. Our fully distributed architecture scales to support hundreds of appliances and zero-cost sensors for virtual and hybrid environments with a single interface.
Corvil's analytics capabilities are deployed as software modules that build upon each other and satisfy the needs of various infrastructure and business teams. Flexible analytics licensing options can lower total cost of ownership over five years by 40% compared to legacy appliance pricing models.
The Right Appliance for Any Business
| Appliance | Network Interfaces | CPU/ Memory | Total Storage2 | Height | Width | Depth | Weight | Power Supply | Redundant PSU |
|---|---|---|---|---|---|---|---|---|---|
| Corvil 6950 | 4 x 1/10Gbps optical/ electrical SFP+ | 24 cores / 128GB | 23TB / 46TB | 1U (1.7in/ 4.32cm) | 16.93in/ 43cm | 27.95in/ 71.0cm | 55lb/ 25kg | 110/240 VAC; 50/60 Hz; 1300W |
YES |
| Corvil 7950 | 4 x 10Gbps optical/ electrical SFP+ | 40 cores / 192GB | 92TB / 184TB | 2U (3.44in/ 8.74cm) | 16.93in/ 43cm | 27.95in/ 71.0cm | 77lb/ 35kg | 110/240 VAC; 50/60 Hz; 1300W |
YES |
| Corvil 8800 | 2 x 40Gbps QSFP / 2 x 100Gbps QSFP28 |
48 cores / 384GB | 92TB / 184TB | 2U (3.44in/ 8.74cm) | 16.93in/ 43cm | 27.95in/ 71.0cm | 77lb/ 35kg | 110/240 VAC; 50/60 Hz; 1600W |
YES |
| Corvil 10000 | 2 x 40Gbps QSFP / 2 x 100Gbps QSFP28 |
64 cores / 512GB | 92TB / 360TB | 2U (3.54in/ 9.0cm) | 19.09in/ 48.5cm | 29.92in/ 76cm | 50.7lb/ 23kg | 240 VAC; 50/60 Hz; 1600W |
YES |
| Corvil Center | N/A | 24 cores / 128GB | N/A | 1U (1.7in/ 4.32cm) | 16.93in/ 43cm | 27.95in/ 71cm | 55lb/ 25kg | 110/240 VAC; 50/60 Hz; 1300W |
YES |
1 Corvil 10000 CPU performance and features will enable 100 million packets per second throughput
2 Raw storage, before compression
| Additional Features | |
|---|---|
| Interoperability | XML WSDL API, SNMPv2/3 MIB, SNMP traps, Syslog, TACACS+, SMTP, RADIUS, LDAP |
| Device Management | Out of Band (Ethernet), Console access, HTTP, HTTPS, Telnet + SSH CLI, SNMP Corvil MIB, MIB-II, Host Resources MIB |
| EMC | FCC CFR 47 Part 15 Class A:2001; EN 55022; 1998 Class A limits; EN 55024:2002 + A2:2003 |
| Safety | UL 60950; CAN/CSA-C22.2 No. 60950; EN 60950; IEC 60950; AS/NZS 60950 |
| Deep Data Buffering | Allows you to size your deployment for average rates, not for the market peaks which may be 10x the average |
